Gate Valve can be divided into rising stem Gate Valve, which refers to the disc doing lift movement in straight line along with the valve stem, and nonrising stem gate valve which refers to the stem nut located in the disc, when the stem rotates, the disc doing lift movement in straight line.
SPECS lined gate valves are commonly used in the cut off applications of chemical, petroleum, pharmaceutical, food, metallurgy, paper, hydropower, environment protection etc.
Size: 1"~12" (DN25~DN300)
Pressure Rating: ASME CLASS 150 (PN16)
Temperature Range: −20 to +200°C
Design and Manufacture: API 600
Face to Face: ASME B16.10
Flange Ends: DIN EN 2532, ANS B16.5, JIS B2220
Visual Inspection: MSS Sp54
Testing: API598,DIN 12569,JIS B2003
Pressure& Temperature: ASME B16.34
Spark Testing: 14Kv
