SPECS pneumatic sanitary Control Valve is suitable for various industrial process control applications, such as food, pharmaceutical, cosmetics, clean steam, wine, beverage, biochemical. It adopts multi-spring diaphragm actuator and sanitary-grade Control Valve body. The Pneumatic Sanitary Control Valves have the advantages of compact structure, convenient assembly and disassembly, high adjustment accuracy, etc., Fully comply with the IEC60534-2006 standard, and the valve leakage is in accordance with the ANSI/FCI 70.2 standard.
The Pneumatic Sanitary Control Valve adopts an angular design to ensure the valve self-discharge, standard electronic polishing, and a smooth surface to ensure cleanliness, no medium accumulation area, and no potential pollution. Quick disassembly and assembly of the valve body and bonnet make the valve maintenance quick and easy, and shorten the process downtime.
Applicable Standard
Design & Manufacture Standard: EHEDG specifications and 3AS standards.
Face to Face: Manufacturer's standard
End Connection: ASME B16.5, ASME B16.11-2009
Test Standard: IEC60534-4
Products Range
Size: 1/2" ~ 4"
Pressure Rating: ASME CLASS 150
Material: Stainless Steel, Alloy Steel, Duplex Steel
End: Clamp type, Threaded type, Flange type
Temperature Range:-20℃~150℃
Seat Leakage：ANSI Ⅳ(0.01%) or Ⅵ(bubble-tight)
Cv: 0.1~175
Flow
Characteristic: EQ%, Linear
Design Features
Pneumatic diaphragm actuator
Made of all stainless steel, clean and non-corrosive
Self-draining angular structure
Perfect support for CIP cleaning and SIP disinfection system
Perfect support for the WFI system of sterile water for injection
PDA certified seals to ensure clean working conditions
The surface of the valve body is electronically polished, and the surface roughness can reach 0.4 microns
