Description
Technical Specifications
Cast steel Gate Valves can only be fully opened and fully closed to be used for cutting in the pipeline.The entire flow channel is a straight-through passage when the valve is fully-open, and the pressure loss of medium running is minimum.Gate Valve is usually for working condition in which the valve is not opened or closed frequently, It's not suitable for adjustment or throttling.
Size: 2" ~ 20"(DN50 ~ DN500)
Pressure Rating: ANSI 150lb ~ 600lb
Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel
Trim: Per API 600
Operation: Handwheel, Gear, Electric, Pneumatic, Hydraulic
