SPECS lined through lift Check Valve only allow one way flow direction and prevent the back-flow of liquids in pipeline. Generally Check Valve is automatically working, under the pressure function of one direction flow, the disc open, while when the liquid back flows, the valve will cut flow.
Size: 1/2"~12" (DN15~DN300)
Pressure Rating: ASME CLASS 150 (PN16)
Temperature Range: −20 to +200°C
Design and Manufacture: API 594
Face to Face: ASME B16.10, DIN 558
Flange Ends: DIN EN 2532, ANS B16.5, JIS B2212
Visual Inspection: MSS Sp54
Testing: API598,DIN 12569,JIS B2003
Pressure& Temperature: ASME B16.34
Spark Testing: 14Kv
