Tilting disc double flange Check Valves, as Check Valve is opened when flow goes through one direction and closes at backflow.
Thanks to the fast closure of this versatile valve, pump protection is one of its main applications. It is used for gases and liquids, bus it is not recommended when there are solids in suspension. The head drop is relatively low.
Design Features
Small flow resistance, easy to open
Quick disc closedown
Installed horizontally and vertically
Size: 2" ~ 24"
Pressure Rating: ASME CLASS 150~2500
Material: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel
End: RF, RTJ, BW
Design & Manufacture Standard: API 594, API 6D
Face to Face: API 594, API 6D
End Connection: ASME B16.5, ASME B16.47
Test Standard: API598, API 6D
