SPECS Full Bore Plug Valves is no diminished flow with the full bore port, and also easy to pigging. For application such as high viscosity condensable media, high efficiency is demonstrated with full bore port.
Applicable Standard
Design Standard: API 599,6D, ASME B16.34
Face to Face: ASME B16.10
End Flange: ASME B16.5
Butt welding Ends: ASME B16.25
Inspection and Test: API 598, API 6D
Products Range
Size: 1/2" ~14" (DN15 ~ DN350)
Rating: 150lb ~ 300LB
Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Stainless Steel
Plug Material: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Stainless Steel
Sleeve(seat) Material: PTFE
Operation : Lever, Gear, Electric, Pneumatic, Hydraulic
Design Features
Full Bore
Rugged,Heavy-Duty Body
Large port opening
Non-Lubricated
