The unidirectional knife Gate Valves are mainly used on industrial pipeline for on-off operation.The valve structure eliminates potential clogging shutoff when the valve is dealing with liquids that contains particles.Beveled knife gate design also generates great shear stress for easy flow penetration.Additionally, beveled knife edge helps the gate cut through thick media easily.
Designed for applications such as:
Pulp & Paper, Water Treatment，Beverage & Food，Fine Chemical,
Power Planet，Steel Industry, etc.
Size: 2"~24"(DN50~DN600 ,larger diameters on request)
Max Working Press.：
DN50~DN250: 10 bar NPS2~NPS10：150 Psi
DN300~DN450: 7 bar NPS12~NPS18：90 Psi
DN500~DN600: 4 bar NPS20~NPS24：60 Psi
Body material: Carbon steel, Stainless steel, Alloy steel, Duplex stainless steel
Gate Material: Stainless Steel Chrome Plated, Special Allory
Seat Material: Stainless Steel+Stellite
EPDM (120°C) /Viton(200°C)/PTFE(200°C) /NBR(90°C)
Temperature Range:-29℃~450℃
Seat Leakage：According to MSS SP-81
Actuator Type: Handwheel, Bevel Gear , Pneumatic and Electric etc.
